Specifications
Mono Power Output
250 watts @ 8 < 0.05 THD
350 watts @ 4 < 0.05 THD
Total Harmonic Distortion
<0.05 @ 1 watt 4 / 100Hz
Signal to Noise Ratio
86 dB below rated output
Crossover Section
Low Pass Filter: 50Hz – 150Hz / 18 dB per octave
(variable with bypass switch)
High Pass Filter: 18Hz / 30 dB per octave (fixed)
System Impedance
8Ω nominal – 4Ω minimum
Current Draw
6.2A @ 350W/4 – 115VAC/60Hz
Dimensions
Width: 19” (482 mm)
Height: 3-1/2” (89 mm) – without feet
Depth: 13-5/8” (346 mm)
Finish
Black anodized aluminum
Weight
Product Weight: 31.3 Lbs. (14.20 kg)
Shipping Weight: 32.5 Lbs. (14.74 kg)
Included Accessories
Removable power cord
Removable rack ears
